Idillium

DESCRIPTION

The IDILLIUM series is the latest solution. Its main feature is its low-noise operation and its traditional design and extremely reduced size makes it look really good in any surroundings. It is available with a wood finishing in two ceiling-mounted models (SL) and one wall- mou nted model (CL), both with medium-high performance levels. Its simple and rational design makes all maintenance and installation operations quick, easy and cost-effectiv The infrared remote control, supplied standard, is used to select one of the three operating speeds by just a press in the button.



Description





Technical specifications

MODEL c.m. SAF – 170S SAF – 340S SAF – 170C
1st speed m3/h 700.0 1400.0 700.0
2st speed m3/h 1200.0 2400.0 1200.0
3st speed m3/h 1700.0 2400.0 1700.0
Noise
1st speed dB 40.0 43.0 40.0
2st speed dB 42.0 45.0 42.0
3st speed dB 51.0 54.0 51.0
Consumption W 125.0 190.0 125.0
Power input V-Hz 230 – 50 / 60 230 – 50 / 60 230 – 50 / 60
Dimensions A x B x C Mm 810 x 468 x 269 760 x 810 x 269 760 x 468 x 269
Weight Kg 29.0 49.0 29.0
Cells n0 1.0 2.0 1.0
Installations Celling Celling Celling Celling
Remote control yes yes yes yes

Nature system

NATURE SYSTEM® technology incorporates the most complete and evolved air treatment system, as can be found in the RIVITALIZZATORE®. Given that the atmosphere contains a variable number of sources of pollution, with the RIVITALIZZATORE® the daytime or night-time operating cycle can beselected. After the operating function has been set, it can automatically control and manage all the operating phases required to achieve the finest air quality. In the daytime cycle, it alternates the purification phase with the revitalisation phase at regular intervals, programmed according to operating speed, while in the nighttime cycle just the revitalisation phase is performed. The control panel constantly displays the function performed and reports any faults and whenmaintenance is required. If filtration is not ideal during the daytime cycle, the system automatically activate the ventilation only phase and disables all the others. The RIVITALIZZATORE®is ideal for city dwellerswhowish to experience the emotion of breathing air that similar to that in natural uncontaminated environments.

AFC system

Its microprocessor independently controls the performance of the electrostatic cell that automatically adjusts the filtration level to the specific operating condition. The information is managed via the control panel. This makes it possible to change the conditions of use at any time, report any faults and signal when the electrostatic cells must be
cleaned. To protect the electronic parts of the machine and constantly assure total reliability, the system automatically stop if the required operation is not performed. In other words, the AFC® system guarantees that optimal performance is constantly maintained whilst minimising external interventions. All the user has to do is to switch on and select the most appropriate speed for his/her requirement and then everything else will be done by the machine.

Basic system

BASIC SYSTEM technology identifies traditional air purification systems with electrostatic filters. This technology is used by all the manufacturers in the sector. Unlike other technologies, its efficiency is not constant as the air filtering performance lowers gradually the dirtier the filter gets. This technology is the simplest and earliest version of electrostatic filtration and works with standard applications and management systems.

The information managed by the electronic circuit and displayed the control panel only shows the
basic functions.
