Vents Inline Fan TTPRO 200

฿7,050.00

VentPro TT Pro fans are the best solution for ventilation of bathrooms and kitchens and other humid premises as well for ventilation of flats, cottages, shops, cafes, etc.

The VentPro TT Pro 200 in line exhaust fan (200mm) has two speeds with the lower setting has an output capacity of 830 m3/hr, the higher setting has an output capacity of 1040 m3/hr. It is Manufactured from high quality low flammable polypropylene with a removable motor block for easy maintenance. Single phase motor with built in thermal overheating protection. The ball bearing motor has a service life up to 40,000 hours at continuous operation. The motor has IPX4 ingress protection rating.

If you wish to switch between the high and low speed you will need to purchase the additional speed controller. See accessories below for the controller and other components designed to be used in conjunction with the fan.

Description

Facts

  • Serie: VentPro Inline Fan TT Pro Series
  • Installation: Duct Type
  • Air Capacity: Max, 1040 m3/h
  • Fan speed max speed: 2380 rpm
  • Sound: 45-52 dB
  • Duct Dimension: 200 mm
  • Voltage / Frequency: 220-230 / 50/60 Hz
  • IP Class: IP X4
  • Power: 76-108 W
  • Current (A): 0.34-0.48
  • Material: Low flammable polypropylene
  • Timer Function: NO
  • Humidity Function: NO
  • Motion Function: NO

CHARACTERISTICS

ParameterТТ PRO 200*
min
ТТ PRO 200*
max
Measurement unit
Max. transported air temperature6060°С
Duct diameter200200mm
Designmixed-flowmixed-flow
Voltage1~2301~230V
Frequency50/6050/60Hz
Current0.340.48A
Sound pressure level at 3 m distance4552dB(А)
Casing materialplasticplastic
Power consumption76108W
Maximum air capacity8301040m³/h
RPM19152380min-1
Protection ratingIP X4IP X4
Weight3.953.95kg
SEC ClassBB
Form-ductsfor round air ductsfor round air ducts
MountingInlineInline
